OEM Support for Air Path and Pressure Control Design
Choose Pinmotor – Your Trusted Micro Pump Suppliers
For OEM projects, this micro vacuum air pump needs to match the full air path, not only the pump position. Pinmotor can support pump selection based on the device function, tubing layout, valve arrangement, air bag size, sealed chamber volume, and pressure control requirements.
The pump can be matched with suction heads, solenoid valves, air bags, filters, sensors, and sealed chambers to support suction, inflation, exhaust, or pressure adjustment. For better sample matching, customers can provide the working mode, target pressure, airflow demand, tubing size, voltage, duty cycle, and installation space.
OEM Support Includes
- Air path layout matching
- Tubing and connector selection
- Valve and air bag matching suggestions
- Suction and pressure requirement confirmation
- Wire length and connector customization
- Sample testing support before bulk production
Specifications and Performance
| Product Model |
528-XA Micro vacuum air pump |
|||||
| Rated voltage | DC 3.7V |
DC 4.5V
|
DC 6V | DC12V |
DC 24V
|
|
| Rated current |
≤1600mA
|
≤1300mA
|
≤1000mA
|
≤500mA |
≤250mA
|
|
| strength |
6.0 W
|
6.0 W
|
6.0 W
|
6.0 W
|
6.0 W
|
|
| outer diameter of air valve |
Ø5.0mm
|
|||||
| Vacuum flow rate (no load) |
2.5-8.0 LPM
|
|||||
|
Maximum vacuum |
≥100 Kpa(750mmHg)
|
|||||
| noise level |
≤ 65 db ( 30cm away) |
|||||
| Life Test | ≥500 hours (continuous) | |||||
| weight | 98g | |||||
Pinmotor can support pump selection, sample matching, and OEM customization for your micro vacuum air pump project.
Contact Pinmotor Engineering Sales
OEM Device Applications
Typical Product Applications
Mini Pneumatic Clamping Device
In a small pneumatic clamping device, this pump can provide air pressure to drive a soft clamp, air bladder, or small actuator. It can be used in light-duty positioning, holding, or fixture systems.
Application Advantage:
Provides air pressure for compact pneumatic clamping or holding structures.
Automated Liquid Dispensing Equipment
This pump can be used in small liquid dispensing systems where air pressure is needed to push liquid from a container or assist fluid movement through tubing. It can work with sealed bottles, valves, and control boards for timed dispensing.
Application Advantage:
Helps generate air pressure for controlled liquid output in compact dispensing devices.
Inflatable Support Cushion
This pump can be used in inflatable lumbar cushions, seat cushions, or small ergonomic support products. It supplies air into the cushion and works with valves to adjust firmness or release pressure.
Application Advantage:
Supports inflation and pressure adjustment in compact cushion or support products.
FAQ
Q: Can this pump handle suction and airflow output in one system?
A: Yes. With the right tubing and valve layout, it can help create negative pressure, move air, support inflation, or release air inside a compact pneumatic device.
Q: Is this pump suitable for use with valves and inflatable parts?
A: Yes. It can be connected with solenoid valves, air tubes, air bags, sealed chambers, or suction heads for air path switching and pressure control.
Q: What details are needed before selecting a pump?
A: Please share the working voltage, required airflow, target pressure or vacuum level, tube size, valve layout, available space, and expected working cycle.
Q: Can I order samples for testing first?
A: Yes. Pinmotor can arrange samples after the application and basic requirements are confirmed. For standard customized samples, the lead time is usually 5–7 working days.
Certified Quality and OEM Manufacturing Support
Our Certificates
CE Certificate of Conformity
Tested according to applicable EMC requirements, supporting product use and documentation needs for international markets.
IATF 16949 Certification
The manufacturing process follows IATF 16949 management standards for stable production control of micro motors and pump products.
ISO 9001 certification
Production and quality control are managed through an ISO 9001 system covering micro pumps, motors, and solenoid valve products.
RoHS certification
Materials comply with RoHS restrictions on hazardous substances, helping meet environmental requirements for electronic and electromechanical products.
Mini Vacuum Air Pump Manufacturing Support
Pinmotor provides OEM/ODM support for pump projects, including parameter confirmation,
sample testing, structure review, mass production, and outgoing inspection.
Customers can send device requirements, and Pinmotor will confirm a suitable pump solution based on the project.
Custom Sample Testing
After parameters are confirmed, Pinmotor can send custom samples within 5–7 working days. Customers can test suction, pressure, noise, temperature rise, and assembly fit.
Parameter
Matching
Pinmotor can confirm DC voltage, flow range, pressure requirement, duty cycle, tubing size, and connector direction according to the device design.
Structure and Installation Review
Pinmotor can review pump size, nozzle position, wire length, connector type, tubing layout, and mounting method based on the customer's device space.
Mass Production and Delivery
After order confirmation, Pinmotor arranges material preparation, production, inspection, and packaging. Standard order lead time is 14–21 working days.
About the Author
Nancy | Engineering Sales Specialist at Pinmotor
Nancy is responsible for project communication and product matching at Pinmotor. She works with OEM and ODM customers on micro pump, micro solenoid valve, and micro motor projects, helping confirm application needs, key specifications, sample arrangements, and customization details before mass production.
Her project experience covers beauty equipment, medical devices, gas sampling instruments, vacuum sealing products, massage equipment, and compact pneumatic systems. Based on daily communication with buyers and product developers, Nancy provides practical guidance on pump selection, air path design, prototype testing, and order preparation.
